Raman spectrometer
Raman spectrometer

Price:   $34,280.00

Add to Cart:

Details:
The Raman2012-785 Raman Spectrometer includes the detector, fiber spectrometer, electronics, probe and laser technologies that provides users with a remarkably sensitive system for demanding low-light level Raman spectroscopy, which is widely used in many research institutes, universities, laboratories for the biological and medical fields to research material composition determination and confirmation.


Features:
Diversity of sampling material
No contact, no damage test
High speed test result
Software control
Water soluble material test

Applications:

Biomedical
Food and pharmacy
Petrochemicals and nanotechnology
Investigative and Forensic
Mineral exploration
Gem identification
Archeology
Environmental science


Model number :Raman2012-785
Dimensions: 405mm×320mm×170mm
Weight: 6.7kg
Laser output power :  > 500mW (50~600mW adjustable)
Laser wavelength : 785±0.05nm
Laser wavelength stability : < 0.05nm
Laser power stability : < 2% (2hrs)
Laser lifetime : > 10,000hrs
Well depth: 200Ke-
Peak QE: 75%
Raman shifting range : 50~4000cm-1
Resolution : <5cm-1
A/D converter: 16 bit 500 kHz
Signal-to-noise ratio: 450:1
Column sensitivity: ~0.32 Counts/e-
Corrected linearity : >99.8%
Data transfer speed : Full scans to memory every 7ms with USB2.0 port
Power-up time : <30 seconds
Operating system : Windows XP / Windows 7
Temperature limits : 0~40ºC, no condensation
Internal power supply : Chargeable Li battery, continuous operating time >3hrs
External power supply (Chargeable) : AC90~250V/50~60Hz
Auto peak finding : Yes
Open Raman data base : Yes
Data inputs/outputs : Yes
Relative analysis : Yes
Compatibility : Dust, water, vibration, intense light proof
