Tm-doped Fiber Laser:


Mode-locking and mode-locking-like operation in a fast gain-switched Tm-doped fiber laser have been investigated experimentally. Applying a SESAM mirror, stable gain-switched and regular mode-locked pulses at a wavelength of m are reported. The repetition rates of the gain-switched pulses and mode-locked sub-pulses are 50 kHz and 111 MHz, respectively. The duration of sub-pulses recorded within one gain-switched pulse envelope is 110 ps. Besides, in the same laser system configuration, it has been found that self-starting mode-locked resembling pulses, attributed to mode beating, can be generated. To the best of our knowledge, it is the first report on a gain-switched fiber laser where both modes of operation have been demonstrated.




Wavelength (nm) : 532
Output Power (mW)  : >1000
Input Voltage (V)   : AC 90~260
Operating Mode   : CW
Cooling Mode   : TEC & Air
Transverse Mode   : TEM00
Beam Diameter at the Aperture (mm)  :  ~2.5
Divergence , Full angle (mrad)   : ≤2.0
Power Stability (RMS/4 hrs)   : <5%
Operating Temperature (℃)   : 10~35
Modulation Mode   :    (TTL / Analog) Optional    ( up to 30kHz)
Laser Head Dimensions  ( L x W x H, mm )  :  150 x 75 x 50
Power Supply Model   : FDA-100B / OEM-100B
Expected Lifetime (hours)  :  10000

Continuous-wave Operation: operation mode of a laser with continuous light emission. Continuous-wave (cw) operation of a laser means that the laser is continuously pumped and continuously emits light. The emission can occur in a single resonator mode (single-frequency operation) or on multiple modes.

A transverse mode of a laser beam is a particular electromagnetic field pattern of radiation measured in a plane perpendicular to the propagation direction of the beam. Transverse Mode has: tem00, near tem00
