HE-CD LASERS / Emitting 325nm
Wavelength (nm): 325
Power (MW):35
Transverse Mode : TEMOO
(Light) Polarization: Linear
Polarization ratio: >500:1
Noise P-P@30khz~-2mhz (%):<15
Light East diameter 1/E2 (mm): <1.2x1
Beam divergence angle (rad): <0.5
Optical pointing stability (uRAD) (constant 250): ≤+25
Warm-up time (90% power) (minutes): 20
Power stability (%) (constant 250): ≤ 2 (4 hours)
Power stability: (10~400) (%) <20
Environmental Conditions (Operation): Temperature 10~40C, Humidity = RH90%*2
Environmental conditions (storage): temperature 10~50C, humidity ≤ RH 90% * 2
Impact (Kimmon Packaging) (G): 20X3
Size (WxHxL) (mm): 146X197X1420
Weight (kg): 23.5
