Blue Laser Module Air-cooled TTL Modulation 2W
Blue Laser Module Air-cooled TTL Modulation 2W

Price:   $299.00  $189.00
Save: 37% off

Add to Cart:

2W blue laser module / Blu-ray module / blue laser air-cooled TTL modulation NDB7875-E

Such products can be widely used in a variety of laser lights with TTL modulation. It can be working for a long time (several hours), real industrial grade laser. We caan provide customers with opto electronic solutions, laser modules designed to meet customer demand.


Host size: 69mm *  30mm * 30mm
Circuit size: 47.5mm * 31.5mm * 16mm
Output wavelength: 445 nm
Output power:1.6-2W
Modulation frequency: modulation
Operating Characteristics: continuous work
Color: Blue
Case Material: Aluminum
Circuits control: Constant Current
Operating voltage: DC = 12V
Operating Current: I <1.7A
Warm-up time:
Operating Temperature: -10 ℃ ~ +40 ℃
Storage temperature: -10 ℃ ~ +40 ℃
Structural features: laser tube + lenses + cooling housing,
Note: The power supply is external.

TTL stands for Transistor-transistor logic . TTL input is a form of modulation, as opposed to analog modulation. If you apply 5V signal to TTL input, laser turns on. You turn the input off, laser goes off. TTL modulation indicates that the laser does not support analog modulation of the output but only ON / OFF control. See blanking. With an RGB laser and TTL blanking you have seven colours at your disposal. Red, Green, Blue, Cyan, Magenta, Yellow, White.
