Feature:
- Power stability, adjustable, easy to operate;
- Original LD, reliable performance, long life;
- Power supply with overheating, current-limiting protection circuit, can be external high-speed modulation;
Application:
- spectrum analysis,
- material analyzing,
- Biological Engineering,
- photoelectric testing,
- medical treatment, etc.
Wavelength (nm): 850±5
Spectral Linewidth (nm): <3
Output Power (mW): 1~1500
Operating Mode: CW
Transverse Mode: Near TE00
Beam Divergence (full angle, mrad): <6
Beam Diameter at Aperture (mm): ~5 x 5
Beam pointing stability(mrad): <0.05
Power Stability (RMS, over 4 hours): <1%,<3%
Aperture Position (mm): 20, 23
Laser Head: Dimensions (L×W×H, mm): 102 x 35 x 35,140 x 49 x 42
Net Weight (kg): 0.3, 0.5
Dimensions (L×W×H, mm): 150 x 110 x 56
Net Weight (kg): 0.6
Cooling System: TEC
Power Supply: 90~240VAC@50Hz
Modulating Repetition: 50KHz TTL / 10KHz Analogue
Warm-up Time (minutes): <5
Operation Temperature (℃) : 0~40
Expected Lifetime (hours): >10000
Warranty Time: 1 year
