30W 976nm multi-mode fiber coupled diode laser module with Coherent bars

(image for) 30W 976nm multi-mode fiber coupled diode laser module with Coherent bars

30W 976nm multi-mode fiber coupled diode laser module with Coherent bars

Applicable Industries:Machinery Repair Shops
Wavelength:976nm
power:30w
Laser type:diode laser
fiber core:105um
Numerical Aperture:0.22NA
Connector:SMA905,ST,FC
Warranty:1 Year
Application1:medical
Application2:pumping laser
Application3:laser marking

30W 976nm multi-mode fiber coupled diode laser modules with Jenoptik bars

Feature: fiber core 105um and 0.22N Numerical Aperture Connector: SMA905 or ST or FC Jenoptik bars High Reliability and high power

Item No.: FC976DL30 Item Name: 30W 976nm Fiber Coupled Diode Laser

Optical

Center Wavelength: 976+-5nm

Output Power :30W

Working Mode: CW

Spectral Width FWHM: 4nm >90%

Power :0.15NA Slope

Efficiency: 2.7W/A

Fiber

Fiber Bend Radius :>60mm

Fiber Length :1m Fiber Core :105um

Fiber Numerical Aperture :0.22NA

Fiber Connector :SMA905

Electrical

Operating Current Iop: 11.5A

Threshold Current Ith: 0.9A

Operating Voltage Vop :5.6V

Power Conversion Efficiency :45%

Thermal

Operating Temperature (Non-Condensing): 15~55

Storage Temperature (Non-Condensing): -30-70

Wavelength Temperature Coefficient :~0.3nm

Write Review

$1,289.00
