1310nm 1.5W High Power Diode Laser
1310nm 1.5W High Power Diode Laser

Price:   $690.00

Add to Cart:

Details: 1310nm 1.5W High Power Diode Laser

Features:
• 1.5W output power
• Reliable Au-Sn solder bonding of chip to open heatsink
• RoHS compliance
Applications:
• Bio Medical
• Material processing
• Night vision

ABSOLUTE MAXIMUM RATINGS:

Reverse current: 25μA
Continuous forward current: 3.5A
Lead soldering temperature: 250 (5sec.)°C
Reverse Humidity: 95%
Operating temperature range:  15~40°C
Storage temperature range:  -40 ~80°C

SPECIFICATIONS

Operating output power : 1.5W
Range of available wavelength : 1310.0nm
Spectral width @ FWHM :  10.0nm
Wavelength temperature tunability : ~0.7nm/°C
Threshold current : 0.3 A
Operating current at Pout : 3.0A
Forward voltage at Pout : 1.3V
Power conversion efficiency : 38%
Slope efficiency : 0.5W/A
Parallel beam divergence : 8.0 deg.
Parpendicular beam divergence : 90*1 μm ×μm
Aperture size
