Features
Optical peak power up to 75 W
Laser wavelength 905 nm
Suited for short laser pulses from 1 to 100 ns
Laser technology including 3 epitaxially stacked emitters
Laser aperture 200 µm × 10 µm
Cost effective plastic package for high volume applications
Applications
Hand-held Laser Range Finders (LRF) for golfers, hunters, civil engineers
Automotive applications (Adaptive Cruise Control (ACC), pre-crash detection, collision
avoidance, adaptive rear lighting)
Traffic surveillance (Laser speed gun, traffic recording, vehicle classification, distance
measurement, fog detection)
Professional laser sensors for distance measuring, positioning, protection
Peak output power: 90W
Peak forward current : 40A
Pulse width (FWHM): 100ns
Duty cycle: 0.1 %
Reverse voltage: 3 V
Operating temperature: - 40~ + 85°C
Storage temperature: - 40 ~ + 100°C
Soldering temperature : + 260°C
