OSRAM 515nm/520nm Green Laser Diodes PL515

Add to Cart:

High Quality OSRAM 515nm/520nm Green Laser Diodes PL515. made in Germany. Green Laser Diode in TO38 ICut Package.

Output  Power: CW 30mW
Working Current: < 180mA
Working Voltage: <8V
Package: 3.8mm
Operating Case Temperature:0~60 ℃
Storage Temperature:-40~85 ℃
Working life: >10,000 hours

•Optical output power (continuous wave): 30mW (TCase = 25°C)
•Typ. emission wavelength: 515nm
•Efficient radiation source for cw and pulsed operation
•Single transverse mode semiconductor laser
•High modulation bandwidth
•Miniaturized TO38 ICut package
•Laser diode isolated against package


•Laser shows
•Biomedical applications
•Laser projection
Safety Advice

Depending on the mode of operation, these devices emit highly concentrated visible light which can be hazardous to the human eye. Products which incorporate these devices have to follow the safety precautions found in IEC 60825-1 “Safety of laser products”.
