Details:
Wavelength (nm): 543±1
Output power (mW): >1, 5, 10, 20, … , 100
Transverse mode: TEM00
Operating mode: CW
Power stability (rms, over 4 hours): <1%, <3%, <5%
Noise of amplitude (rms, 1~20MHz): <1%
Warm-up time (minutes): <10
M2factor: <1. 2
Beam divergence, full angle (mrad): <1. 5
Beam diameter at the aperture (mm): ~2. 0
Beam height from base plate (mm): 24. 8
Polarization ratio: >100:1 (0 or 90 degree)
Pointing stability after warm-up (mrad): <0.05
Operating temperature (℃): 10~35
Power supply (90-264VAC or 5VDC): PSU-III-LED; PSU-III-FDA; PSU-III-OEM;
Expected lifetime (hours): 10000
Warranty: 1 year
