10W 975nm Uncooled Multimode Laser Diode Module

Key Parameters:
l  Basedon single fire spot laser module
l  Highoutput power 10W
l  Highstability
l  0.22NA 105μmcore multimode fiber
l  Parallelweld 2-Pin sealed package
l  Standardcentral wavelength 915nm/940nm/975nm
l  RoHS  compliance

Application:
l  Medical
l  Printing
l  pumpsource
l  Materialprocessing


Parameter

MIn.

TYP.

Max.

Unit

Conditions

CW Output Power

10

-

-

W



Centre Wavelength

-

975±10

-

Nm



Spectral Width

-

3.5

-

Nm



Threshold Current

-

0.55

0.9

A



Operating Current

-

11.5

12.5

A



Operating Voltage

-

1.8

2.2

V



Convention Efficiency

-

48

-

%



>90% Power

-

0.12

-

NA



Wavelength Tuning vs. Temperature

-

0.3

-

NM/



Slop Efficiency

-

0.9

-

W/A



Storage Temperature

-30

-

70

Non-Condensing

Operating Temperature

15

-

55



Fiber Bend Radius

37.5

-

-

Mm



Buffer Diameter

-

250

-

μm



Cladding Diameter

-

125

-

μm



Core Diameter

-

105

-

μm



Numeric Aperture

-

0.22

-

-



Fiber Connector

-

CO

-

-

SMA905,FC
